The leading automated optical inspection (AOI) machine manufacturers in 2026 are Koh Young, Omron, Saki, Test Research (TRI), Viscom, Mirtec, Nordson Test & Inspection, ViTrox, Parmi and Mek for SMT and PCB assembly, and Camtek and Machine Vision Products (MVP) for semiconductor and advanced packaging. Koh Young has held the top position in 3D AOI since 2013. Analysts put the AOI market at roughly USD 0.9 to 1.9 billion in 2025, depending on scope. This guide covers the 12 companies, the three types of AOI machine, and six criteria for shortlisting equipment for electronics and PCB inspection.
Key Notes
12 manufacturers, grouped by segment: 10 build SMT and PCB assembly AOI, 2 build semiconductor and advanced packaging AOI.
3D AOI is the default for new SMT lines; one 2025 estimate puts inline systems at 87 percent of 3D AOI units shipped.
Typical resolutions: 10 to 15 µm for 2D PCB AOI, 5 to 12.5 µm for 3D SMT AOI, 1 to 5 µm for die and packaging AOI.
Every vendor on this list ships AI-assisted programming or AI false-call reduction as of 2025; the difference is depth, not presence.
AOI hardware and AI inspection software are now separate buying decisions. An AI layer can run on the AOI machines you already own.
The three types of AOI machine
An AOI machine is a camera, lighting and motion platform that images a board or device and classifies defects in software. Three machine types cover almost every buyer on this list.
Type
What It Measures
Typical Resolution (2025 Examples)
Where It Runs
Vendors Below
2D AOI
Presence, polarity, offset, solder shape from top and angled images
10 to 15 µm (TRI TR7700 SII DT: 15 µm; TR7700L SIII Plus: 5.5 or 10 µm)
Desktop or inline, SMT and THT
Mek, TRI, MVP
3D AOI
Component height, coplanarity, solder volume by moiré or laser profilometry
5 to 12.5 µm (Omron VT-S1080: 12.5 µm; Koh Young Zenith under 10 µm)
Inline machines sit on the conveyor between the placement machine, reflow oven and AXI. They inspect every board at line speed. Every 3D vendor below sells inline first.
Desktop or offline machines inspect sampled or low-volume boards beside the line. Mek, Mirtec (MV-3 OMNI) and TRI (TR7700 SII DT) are the main desktop options on this list.
How the 12 are ranked. Order inside each segment follows verified market position first, then relevance to high-mix and high-reliability buyers. Ratings are editorial and reflect breadth of portfolio, documented 2025 releases, and service footprint.
SMT and PCB assembly AOI manufacturers
1. Koh Young Technology
Best for: measurement-based 3D AOI on high-volume SMT lines
Koh Young Technology, headquartered in Seoul, South Korea, has held the top position in 3D AOI since 2013 and in 3D solder paste inspection since 2006. As of October 2025 the company reports more than 24,000 machine installations and 3,800 customers worldwide. Its Zenith 2 AOI applies True 3D measurement rather than image comparison, which is why its false-call rates are the benchmark the rest of the market quotes.
Features
Zenith 2 and Zenith UHS AOI: full 3D measurement of every component and solder joint, with the UHS variant tuned for throughput.
aSPIre3 and KY8030 SPI: solder paste inspection on the same measurement principle, so SPI and AOI data correlate.
Meister series: 3D inspection and metrology for semiconductor and wafer-level packaging, with a Taiwan office opened in August 2025 to serve that market.
KSMART software: AI-driven programming, process control and line analytics across SPI and AOI.
Pros:
Largest installed base in 3D AOI and SPI: Mature libraries and fast recipe sharing
Closed-loop correction: Measurement data feeds printer and mounter adjustments
Global service network: Support across Asia, Europe and the Americas
Cons:
Request quotes alongside Asian alternatives; measurement-grade 3D commands a premium
Needs trained process engineers: Smaller shops may underuse the 3D measurement data
Best for: solder-joint inspection on a single upgradeable 3D AOI platform
Omron, headquartered in Kyoto, Japan, has 35 years of AOI history inside its Industrial Automation business. Its current VT-S10 series puts three machines on one platform: the VT-S1080 for maximum inspection coverage, the VT-S1040 for balanced needs, and the VT-Z600 for high-speed 2D. All are field upgradeable, and the VT-S1080 won the Circuits Assembly NPI Award in 2022 for 3D solder-joint inspection. For a deeper look, see Omron AOI.
Features
MDMC illumination: multi-direction, multi-color lighting that suppresses shadowing and secondary reflection on solder fillets.
Camera setup: 12 MP top camera at 12.5 µm plus four 5 MP side cameras on the VT-S1080.
AI-assisted programming: reduces recipe creation time and operator skill requirements.
Line integration: pairs with Omron’s VT-X750 3D CT AXI under the company’s Zero Defect concept.
Pros:
One platform from 2D to 3D: High-speed 2D through full 3D, upgradeable in the field
Deep solder-joint expertise: IPC-referenced quantitative measurement
In-house components: Omron’s own controllers, sensors and safety parts simplify maintenance
Cons:
Younger Americas installed base: Strongest in Asia and Europe
Best for: upgradeable optics and AI false-call reduction
Saki Corporation, headquartered in Tokyo, Japan, began shipping its 3Si/3Di-EX series of 3D SPI and AOI systems in April 2025. The series separates the optical unit from the platform, so a line can upgrade cameras and projectors without replacing the machine. AI Assist re-evaluates called defects to cut false positives, and AI OCR reads markings despite print variation. Saki also sells the 3Di-LS3EX high-speed 3D AOI and a full AXI range.
Features
3Di-EX 3D AOI: modular, upgradeable optical units on Saki’s high-rigidity gantry.
AI Assist and AI OCR: AI re-evaluation of defects and character inspection, available on the 3Di-EX AOI series.
Saki Link: machine-to-machine connection of SPI and AOI with centralized control across a line.
One Programming: a single programming flow across Saki SPI, AOI and AXI.
Pros:
Hardware upgrade path: Protects the capital spend over the platform’s life
Complete line coverage: SPI to AXI from one vendor
Made-in-Japan build quality: Strong adoption in automotive
Cons:
Confirm local service coverage in the Americas before purchase
Fewer entry-level options: Less desktop and entry-level choice than Mek or Mirtec
Best for: highest-throughput inline AOI with Smart Factory standards built in
Test Research, Inc. (TRI), headquartered in Taipei, Taiwan, sells the broadest test-and-inspection portfolio in the SMT market: SPI, AOI, AXI and in-circuit test. Its TR7700 SIII Ultra AOI inspects up to 60 cm² per second and ships in a dual-lane configuration. In June 2025 TRI added the TR7500 SIII Ultra, a multi-camera AOI with four side cameras and one top camera, and in July 2025 a size-M platform that handles boards up to 660 x 690 mm.
Features
TR7700 SIII Ultra: 60 cm²/sec high-speed AOI with AI algorithms, Smart Programming and metrology measurements.
TR7500 SIII Ultra: five-camera side-view AOI with optional AI inspection, metrology and 3D laser imaging.
Smart Factory standards: IPC-CFX, IPC-DPMX and The Hermes Standard (IPC-HERMES-9852) supported natively.
YMS 4.0: Industry 4.0 yield management that links SPI, AOI, AXI and ICT data.
Pros:
Full-line coverage: One vendor for inspection and test, with shared programming and data
Dual-lane and large-board options: Suited to automotive and industrial assemblies
Open standards: Lower integration cost with MES and line controllers
Cons:
Broad portfolio: Configuration choices are harder for first-time buyers
2D-first heritage: Some models deliver 3D through optional laser sensors rather than full-field moiré
Best for: European automotive and high-reliability electronics
Viscom SE, headquartered in Hanover, Germany, has built optical and X-ray inspection systems since 1984 and is listed on the Frankfurt Stock Exchange. Its flagship iS6059 PCB Inspection Plus 3D AOI captures images up to 25 percent faster with a next-generation 3D camera. At productronica in November 2025 Viscom introduced vAI Provision, AI-powered generation of 3D AOI and 3D AXI inspection programs. Revenue in 2025 was EUR 81.7 million, down on weak European demand, with stabilization expected in 2026.
Features
iS6059 PCB Inspection Plus: premium 3D AOI with faster imaging and Viscom’s XM camera sensor lineage.
vAI Provision: AI program generation for 3D AOI and 3D AXI, launched 2025.
X8011-III: 2D and 3D X-ray for automated and manual workflows, so AOI and AXI share one software environment.
Energy-storage inspection: X-ray systems for battery cells, relevant to EV supply chains.
Pros:
Deep automotive qualification: Long history across German Tier 1 suppliers
AOI and AXI from one vendor: Shared programming across both
Global service presence: European engineering and service, plus Americas and Asia segments
Cons:
2025 revenue decline and restructuring: Confirm roadmap commitments in the sales process
European price band: Asian challengers undercut on comparable specs
Best for: high-resolution multi-camera 3D AOI, including a semiconductor packaging variant
Mirtec, headquartered in Gunpo, Gyeonggi-do, South Korea, with a US office in Oxford, Connecticut, builds 2D and 3D AOI and SPI systems for consumer electronics, automotive and telecommunications assembly. Its OMNI-VISION technology combines a 15 or 25 megapixel CoaXPress camera with multi-projection moiré 3D. At SEMICON West 2025 Mirtec showed the MV-9SIP hybrid 3D system for semiconductor packaging inspection. With a commitment to quality and innovation, Mirtec solidifies its reputation as a global supplier, providing the technology and support needed to meet the complexities of today’s manufacturing processes.
Features
OMNI-VISION 3D: 15 or 25 MP CoaXPress top camera with 8 or 12 projection moiré, plus four side cameras on the MV-6 OMNI.
MV-9 and MV-9SIP: high-end 3D AOI for precision applications; the SIP variant targets semiconductor packaging.
MV-3 OMNI: desktop 3D AOI with the same optics as the inline MV-6 OMNI.
Global support: service centers worldwide ensure quick and efficient support.
Pros:
Scalable range: Suitable for businesses of all sizes
Strong R&D focus: Continuous development across the product line
INTELLISYS Industry 4.0 software: Closed-loop communication with screen printers
Cons:
Proprietary components: Could lead to higher long-term maintenance costs
Complex setup: May require skilled operators initially
Best for: AOI, SPI and coordinate metrology in one system
Nordson Test & Inspection, a division of Nordson Corporation of Westlake, Ohio, acquired CyberOptics of Minneapolis in November 2022 and now sells its AOI line alongside Nordson’s X-ray portfolio. The SQ3000 and SQ3000M2 combine AOI, SPI and coordinate measurement in a single machine, built on CyberOptics’ Multi-Reflection Suppression (MRS) sensors. MRS sensors reach 5 µm lateral and 0.1 µm height resolution, which is why the platform also serves mini LED, micro LED and advanced packaging inspection.
Features
SQ3000 and SQ3000M2: multi-function AOI, SPI and CMM measurement; the M2 won the Prime Award at the Step-by-Step Excellence Awards.
MRS sensor technology: suppresses erroneous measurements from reflective surfaces such as wafers and bright substrates.
AI² (Autonomous Image Interpretation): modeling software that classifies features and contamination without rule-by-rule programming.
X-ray adjacency: Nordson’s inline and offline AXI for hidden joints and stacked packages.
Pros:
Fast coordinate measurement: Seconds rather than CMM hours, on the same inspection pass
One sensor technology: Spans SMT and back-end semiconductor
US headquarters: With global support
Cons:
Capability is metrology-grade; confirm the price fits a plain SMT line
Best for: dual-sided 3D AOI and AI programming at Asian EMS scale
ViTrox Technologies, headquartered in Penang, Malaysia, marked 25 years in 2025 and sells SPI, 3D AOI, AXI and robotic vision systems with offices in Germany and the United States. Its V510i DST dual-sided 3D AOI won the Circuits Assembly NPI Award in March 2025, and the V510Ai DST that followed in August 2025 offers 100 mm top clearance for THT assemblies. The V510i Semicon AOI and Micro AOI variants inspect wire bonds, die defects and solder bumps for advanced packaging.
Features
V510i Optimus 3D AOI: inline 3D AOI for SMT with AI parameter checking, recipe quality control and fine-tuning.
V510Ai DST: simultaneous top and bottom 3D inspection in one machine, which removes board flipping and a second AOI.
V510i Semicon and Micro AOI: optimized for highly reflective dies and components; ViTrox claims up to 50 percent yield improvement for packaging customers.
V-ONE digital factory: line analytics integrated at Jabil and other EMS sites.
Pros:
Dual-sided inspection: Cuts cycle time on mixed SMT and THT lines
Competitive pricing: Backed by a large Southeast Asian EMS installed base
Packaging variant: Semiconductor packaging inspection on the same platform
Cons:
European presence runs through the Germany office; confirm service response times
North American brand recognition: Still trails the Korean and Japanese leaders
Operating out of South Korea, Parmi Co., Ltd. has made a significant mark in the AOI sector, gaining acclaim for its high-speed inline systems used in consumer electronics and automotive assembly across Asia. PARMI USA launched the company’s next-generation 3D AOI, the Xceed II, at IPC APEX EXPO in March 2025. As Juan Arango, Head of Sales and Business Development at PARMI USA, put it, the improvements in speed, precision and die inspection optimization make the Xceed II the company’s most advanced AOI system for high-demand, high-precision environments. In August 2025 PARMI USA appointed Prosperar Solutions as its representative in Brazil, extending Americas coverage.
Features
SPI integration: combines solder paste inspection with AOI for seamless defect detection.
Machine learning algorithms: real-time defect detection enhanced by AI.
Xceed II 3D AOI: high-throughput inline system with die inspection optimization, launched March 2025.
Pros:
Seamless SMT line integration
Advanced AI-driven defect classification
Cons:
High initial costs: Advanced models may deter some buyers
Speed versus precision: High-speed modes at 14 µm resolution trade precision for throughput, which limits use in the most demanding applications
Best desktop and compact AOI for European SMEs and THT lines
Mek (Marantz Electronics) developed its first AOI system in Japan in 1994, when Marantz was part of Philips, and shipped its first commercial desktop system in 1997. Mek Europe BV, based in Tilburg in the Netherlands, is the sales and support base for Europe, the Americas and India. With over 10,000 AOI machines in use worldwide as of 2024, Mek’s systems are widely adopted in quality control for PCB manufacturing and electronics assembly. They predominantly serve small to medium-sized enterprises across Europe, from the UK to Germany and down to Spain, which suits manufacturing engineers and production managers who prioritize quality without compromising on space or budget. Mek is a partner in the ITEA ExplAIn project with Prodrive, Signify and TU Delft, developing explainable AI for AOI in electronics manufacturing.
Features
ISO-Spector M2 full 3D AOI: inline 3D topographical and imaging AOI, the latest in the ISO-Spector line introduced in 2011.
SpectorBOX system: innovatively designed for inspecting Through-Hole Technology (THT) components.
PowerSpector and iSpector desktop AOI: compact systems that share the 22X software engine with Mek’s inline machines.
Flexible configurations: adaptable for both inline and offline use.
Pros:
Compact design: Fits in limited factory spaces
Accurate detection: Solder joint defects and component misplacements
European customer support: Extensive coverage across the continent
Published AOI ROI calculator: Released in 2025, it helps SMEs build the business case
Cons:
Volume limits: Not ideal for high-volume production
Limited AI depth: Advanced AI and machine learning integration is still largely in research partnerships rather than shipping products
Semiconductor and advanced packaging AOI manufacturers
Back-end fabs and OSATs buy AOI for die, wire-bond, bump and wafer-level defects at 1 to 5 µm, a different machine class from SMT AOI. Two specialists lead this segment on our list, and four SMT vendors above (Nordson, ViTrox, Mirtec and Koh Young’s Meister line) sell packaging variants. Front-end wafer inspection is a separate market: KLA and Onto Innovation dominate optical and e-beam wafer inspection in the fab, and those tools are covered under semiconductor visual inspection rather than here.
11. Camtek
Best for: advanced packaging and HBM inspection and 3D metrology
Camtek, headquartered in Migdal HaEmek, Israel, reported record 2025 revenue of USD 496.1 million, up from USD 429 million in 2024, driven by high-performance computing and advanced packaging. Its Eagle G5 and Hawk systems inspect and measure wafers from the mid-end through post-dicing, and Camtek is the tool of reference for HBM4 3D metrology at every major HBM manufacturer. In the third quarter of 2025, HPC applications were about 45 percent of revenue and other advanced packaging about 25 percent. For how Camtek’s approach compares with AI-based AOI, see Camtek inspection vs AI AOI.
Features
Eagle G5: 2D and 3D inspection platform for advanced interconnect packaging, chiplets and hybrid bonding.
Hawk: 3D metrology with the highest throughput and accuracy in Camtek’s range; an enhanced version is planned for early 2026.
Best AOI for aerospace, defense, medical and microelectronics packaging
Based in Vista, California, Machine Vision Products, Inc. (MVP) builds AOI for industries where precision is paramount: aerospace, defense and medical devices, plus die, wire-bond and BGA inspection for semiconductor packaging. In 2023, MVP proudly celebrated its 30th anniversary, reflecting its ability to adapt and thrive amidst the continuously evolving demands of manufacturing. In May 2025 MVP began assembling its flagship MVP 900 Series AOI systems in Malaysia to serve Asian electronics manufacturers, and at productronica in November 2025 it showed AI-driven defect detection for wafer, die, wire-bond, BGA and micro-assembly inspection.
Features
Multi-camera systems: ultra-high resolution for comprehensive inspections, with pixel sizes down to 1 µm on the 850 platform.
MVP 900 Series: die and wire, BGA and die-surface AOI, now assembled in the US and Malaysia.
MVP Aurora: 2.5 to 20 µm optics, 2D field of view up to 60 mm, 3D accuracy to ±20 µm.
Versa Duo: laser-based 3D with 0.5 µm repeatability, unveiled at IPC APEX 2024.
MES integration: seamlessly connects with Manufacturing Execution Systems for operational efficiency.
Pros:
Unmatched accuracy: Caters to highly regulated industries
Customizable inspection parameters
Made in the USA: Matters for defense and ITAR programs
Cons:
Built for precision applications rather than high-volume SMT throughput
Smaller company: Than the Asian leaders, so confirm regional service coverage
Comparison: Best Automated Optical Inspection Companies
Company
HQ
Segment
Full 3D AOI
SPI on Same Platform
AI Programming or AI False-Call Reduction
Semiconductor or Packaging Variant
Service Regions
Koh Young
South Korea
SMT
Yes
Yes
Yes (KSMART)
Yes (Meister)
Global
Omron
Japan
SMT
Yes
No (AXI yes)
Yes
No
Global, strongest Asia and Europe
Saki
Japan
SMT
Yes
Yes
Yes (AI Assist, AI OCR)
No
Asia, Europe, Americas
TRI
Taiwan
SMT
Yes (laser option)
Yes
Yes
Yes (TR7600 SIII Plus AXI for OSAT)
Global
Viscom
Germany
SMT
Yes
Yes
Yes (vAI Provision)
No
Europe, Americas, Asia
Mirtec
South Korea
SMT
Yes
Yes
Partial
Yes (MV-9SIP)
Global
Nordson Test & Inspection
United States
SMT and packaging
Yes
Yes (same machine)
Yes (AI²)
Yes (SQ3000+)
Global
ViTrox
Malaysia
SMT and packaging
Yes
Yes
Yes
Yes (V510i Semicon, Micro AOI)
Asia, Germany, United States
Parmi
South Korea
SMT
Yes
Yes
Yes
No
Asia, Americas
Mek (Marantz Electronics)
Japan and Netherlands
SMT, THT, desktop
Yes (ISO-Spector)
Yes
Research stage
No
Europe, Americas, India, Japan
Camtek
Israel
Semiconductor packaging
Yes (metrology)
No
Yes
Core business
Asia-centric, global
MVP
United States
Packaging and high-reliability SMT
Yes (Versa Duo, Aurora)
Yes (Versa)
Yes
Core business
United States, Malaysia, Europe
How big is the AOI market in 2026?
The AOI equipment market is worth roughly USD 0.9 to 1.9 billion in 2025, depending on how analysts scope it. Grand View Research estimates USD 955 million in 2025 growing at 8.9 percent a year to 2033; 360iResearch estimates USD 1.61 billion in 2024 growing at 19 percent a year to USD 4.6 billion by 2030. The spread comes from whether software, SPI and semiconductor packaging inspection are counted.
Concentration: the top five 3D AOI vendors hold about 64 percent of that segment, by one 2025 estimate (QYResearch).
Geography: Asia Pacific accounts for about 69 percent of 3D AOI demand; inline systems are about 87 percent of 3D AOI units.
Unit economics: one 2024 estimate (YH Research) puts global SMT AOI shipments at about 8,900 units at an average price near USD 62,600.
Drivers named by every analyst: automotive electronics, miniaturized components (0201 metric and below), and advanced packaging for AI accelerators and HBM.
For what individual machines cost by type and vendor, see AOI machine prices.
How To Choose The Best Automated Optical Inspection Company?
Six criteria separate the 12 manufacturers above. Score each vendor against your line before the demo, not after.
1. Inspection Speed vs. Precision
Higher speeds suit mass production; precision is the priority in regulated sectors such as aerospace and medical devices. Rated speeds and resolutions are published, so compare them directly.
If speed is your main criterion, TRI’s TR7700 SIII Ultra is rated at 60 cm²/sec, and Parmi and Koh Young’s Zenith UHS compete in the same band.
For precision, consider MVP (pixel sizes down to 1 µm) or Nordson’s MRS sensors (5 µm lateral, 0.1 µm height) for packaging-grade work.
2. 3D measurement, not just 3D imaging
3D measurement matters when solder volume, coplanarity and lifted leads are escaping 2D inspection. Moiré-based measurement (Koh Young, Mirtec, Saki, Omron) gives height data on every joint; laser-sensor 3D (TRI options, MVP Versa Duo) adds height on selected features at lower cost. Ask the vendor whether the 3D data is measured in microns or inferred from images.
3. Line integration: SPI, AXI and standards
Check how well the system integrates with the inspection steps around it and with your MES.
SPI and AOI from one vendor on one measurement principle (Koh Young, Saki, TRI, Viscom, Mirtec, Nordson) lets printer offsets be corrected from AOI data.
Systems with MES connectivity, like MVP’s, and native IPC-CFX and Hermes support, like TRI’s, cut integration cost.
Vendors with AXI in the same software environment (Omron, Viscom, Saki, TRI, Nordson) simplify hidden-joint coverage.
4. False-call rate and programming time
False calls are the operating cost of AOI: every call an operator reviews is labor, and every loosened threshold is an escape risk. In 2025 every vendor on this list ships AI-assisted programming or AI re-evaluation (Omron AI programming, Saki AI Assist, Viscom vAI Provision, ViTrox AI parameter checker, TRI Smart Programming). Ask for the false-call rate on your own boards during the demo, and for the time to program a new product from CAD.
5. Regional Availability and Support
The reach and support services of the provider can greatly impact operational efficiency and downtime.
Regional providers like Mek and Viscom offer strong support within Europe, ensuring prompt service.
Global players like Koh Young, Omron, TRI and Mirtec offer a widespread service network, beneficial for multinational operations.
US buyers with defense or medical programs should weigh MVP and Nordson’s domestic presence.
6. Total cost and the software decision
Inline 3D AOI machines typically run from the tens of thousands into the low hundreds of thousands of dollars depending on resolution, 3D method and lane count; see AOI machine prices for a breakdown by type and vendor. Before replacing hardware to get better AI classification, check whether an AI software layer on your existing AOI machines closes the gap, which is the subject of the next section.
AI software that runs on top of AOI machines
AOI hardware and AI classification software are now separate buying decisions. Every machine above produces images and a first-pass defect call; an AI inspection layer can read those images, reclassify the calls, and cut the false-positive queue without changing the hardware.
Averroes.ai is an AI visual inspection platform that runs on top of existing AOI, KLA, Onto, e-beam and line-scan systems. It trains custom defect classification and detection models from 20 to 40 images per defect class, reaches 99 percent plus classification accuracy on production data, and deploys on-premise so no images leave the plant.
When this route fits: your AOI hardware images the defects correctly but the rule-based software over-rejects, your line has rare defect classes with few samples, or you run several AOI brands and want one classification layer across them.
When it does not: your optics cannot resolve the defect in the first place. No software recovers a feature the camera did not capture, which is why resolution sits first in the criteria above.
AI-native AOI hardware is also emerging: Delvitech’s Horus, shown at IPC APEX 2025, is marketed as an all-in-one AI-native platform for AOI and SPI.
Want 99%+ Accuracy From the AOI Machines You Already Own?
Add an AI inspection layer to your existing AOI fleet, no new hardware needed
Frequently Asked Questions
What is the primary benefit of using Automated Optical Inspection systems?
Automated Optical Inspection systems significantly enhance manufacturing quality control by providing high precision in defect detection, reducing human error, and increasing throughput speeds.
How does the SPI integration in AOI systems benefit manufacturing?
SPI integration in AOI systems streamlines the inspection process by combining solder paste inspection with optical checks, ensuring higher detection accuracy and smoother production lines. When both run on the same measurement principle, as at Koh Young, Saki, TRI and Nordson, paste volume data can be correlated with post-reflow joint defects and fed back to the printer.
What factors should you consider when upgrading to a new AOI system?
When upgrading, consider the new system’s compatibility with existing processes, its ability to scale with your production needs, and the level of technical support available from the provider. Also weigh total cost, covered in AOI machine prices, against an AI software upgrade on the machines you already own.
How does AI change automated optical inspection?
AI changes AOI in two places. In programming, AI generates inspection recipes from CAD and component libraries in minutes rather than hours, as Omron, Viscom and Saki now ship. In classification, AI models trained on a plant’s own defect images re-evaluate every call and reduce false positives, either inside the machine or as a separate software layer such as Averroes.ai running on existing AOI output.
What is the difference between an AOI machine and a machine vision system?
An AOI machine is a complete inspection station built for one job, usually PCB assembly or die and package inspection, with fixed optics, lighting, conveyor handling and defect libraries. A machine vision system from vendors such as Cognex or Keyence is a camera, lens and software toolkit that an integrator configures for any task, from code reading to presence checks. For that comparison, see Cognex vs Keyence vision systems.
Conclusion
Selecting the right AOI system is critical for manufacturing quality control.
Koh Young leads 3D AOI on installed base and measurement depth; Omron, Saki, TRI and Viscom are the established alternatives for SMT lines; Mirtec, Nordson, ViTrox and Parmi compete on resolution, speed or price; Mek serves European SMEs and THT; Camtek and MVP own the semiconductor and packaging segment.
When making your decision, consider the balance between inspection speed and precision, true 3D measurement, integration with SPI and AXI, false-call rate, regional support, and total cost. These factors will guide you toward the machine that fits your line.
Ready to improve classification accuracy on the AOI hardware you already run? Request a free demo from Averroes.ai and see how an AI inspection layer reaches 99 percent plus accuracy while working with your existing equipment.
![Top 12 Automated Optical Inspection (AOI) Machine Manufacturers [2026]](/_next/image?url=https%3A%2F%2F303922.eu15.myftpupload.com%2Fwp-content%2Fuploads%2F2025%2F03%2FAverroes.ai-Blog-Covers-JA-1.png&w=3840&q=75)
![Inspection Methods Explained [Manual, Remote & Visual]](/_next/image?url=https%3A%2F%2F303922.eu15.myftpupload.com%2Fwp-content%2Fuploads%2F2026%2F07%2FAverroes.ai-Blog-Covers-JA-4.jpg&w=3840&q=75)
The leading automated optical inspection (AOI) machine manufacturers in 2026 are Koh Young, Omron, Saki, Test Research (TRI), Viscom, Mirtec, Nordson Test & Inspection, ViTrox, Parmi and Mek for SMT and PCB assembly, and Camtek and Machine Vision Products (MVP) for semiconductor and advanced packaging. Koh Young has held the top position in 3D AOI since 2013. Analysts put the AOI market at roughly USD 0.9 to 1.9 billion in 2025, depending on scope. This guide covers the 12 companies, the three types of AOI machine, and six criteria for shortlisting equipment for electronics and PCB inspection.
Key Notes
The three types of AOI machine
An AOI machine is a camera, lighting and motion platform that images a board or device and classifies defects in software. Three machine types cover almost every buyer on this list.
Inline versus offline
How the 12 are ranked. Order inside each segment follows verified market position first, then relevance to high-mix and high-reliability buyers. Ratings are editorial and reflect breadth of portfolio, documented 2025 releases, and service footprint.
SMT and PCB assembly AOI manufacturers
1. Koh Young Technology
Best for: measurement-based 3D AOI on high-volume SMT lines
Koh Young Technology, headquartered in Seoul, South Korea, has held the top position in 3D AOI since 2013 and in 3D solder paste inspection since 2006. As of October 2025 the company reports more than 24,000 machine installations and 3,800 customers worldwide. Its Zenith 2 AOI applies True 3D measurement rather than image comparison, which is why its false-call rates are the benchmark the rest of the market quotes.
Features
Pros:
Cons:
2. Omron
Best for: solder-joint inspection on a single upgradeable 3D AOI platform
Omron, headquartered in Kyoto, Japan, has 35 years of AOI history inside its Industrial Automation business. Its current VT-S10 series puts three machines on one platform: the VT-S1080 for maximum inspection coverage, the VT-S1040 for balanced needs, and the VT-Z600 for high-speed 2D. All are field upgradeable, and the VT-S1080 won the Circuits Assembly NPI Award in 2022 for 3D solder-joint inspection. For a deeper look, see Omron AOI.
Features
Pros:
Cons:
3. Saki Corporation
Best for: upgradeable optics and AI false-call reduction
Saki Corporation, headquartered in Tokyo, Japan, began shipping its 3Si/3Di-EX series of 3D SPI and AOI systems in April 2025. The series separates the optical unit from the platform, so a line can upgrade cameras and projectors without replacing the machine. AI Assist re-evaluates called defects to cut false positives, and AI OCR reads markings despite print variation. Saki also sells the 3Di-LS3EX high-speed 3D AOI and a full AXI range.
Features
Pros:
Cons:
4. Test Research, Inc. (TRI)
Best for: highest-throughput inline AOI with Smart Factory standards built in
Test Research, Inc. (TRI), headquartered in Taipei, Taiwan, sells the broadest test-and-inspection portfolio in the SMT market: SPI, AOI, AXI and in-circuit test. Its TR7700 SIII Ultra AOI inspects up to 60 cm² per second and ships in a dual-lane configuration. In June 2025 TRI added the TR7500 SIII Ultra, a multi-camera AOI with four side cameras and one top camera, and in July 2025 a size-M platform that handles boards up to 660 x 690 mm.
Features
Pros:
Cons:
5. Viscom SE
Best for: European automotive and high-reliability electronics
Viscom SE, headquartered in Hanover, Germany, has built optical and X-ray inspection systems since 1984 and is listed on the Frankfurt Stock Exchange. Its flagship iS6059 PCB Inspection Plus 3D AOI captures images up to 25 percent faster with a next-generation 3D camera. At productronica in November 2025 Viscom introduced vAI Provision, AI-powered generation of 3D AOI and 3D AXI inspection programs. Revenue in 2025 was EUR 81.7 million, down on weak European demand, with stabilization expected in 2026.
Features
Pros:
Cons:
6. Mirtec Co., Ltd.
Best for: high-resolution multi-camera 3D AOI, including a semiconductor packaging variant
Mirtec, headquartered in Gunpo, Gyeonggi-do, South Korea, with a US office in Oxford, Connecticut, builds 2D and 3D AOI and SPI systems for consumer electronics, automotive and telecommunications assembly. Its OMNI-VISION technology combines a 15 or 25 megapixel CoaXPress camera with multi-projection moiré 3D. At SEMICON West 2025 Mirtec showed the MV-9SIP hybrid 3D system for semiconductor packaging inspection. With a commitment to quality and innovation, Mirtec solidifies its reputation as a global supplier, providing the technology and support needed to meet the complexities of today’s manufacturing processes.
Features
Pros:
Cons:
7. Nordson Test & Inspection (CyberOptics)
Best for: AOI, SPI and coordinate metrology in one system
Nordson Test & Inspection, a division of Nordson Corporation of Westlake, Ohio, acquired CyberOptics of Minneapolis in November 2022 and now sells its AOI line alongside Nordson’s X-ray portfolio. The SQ3000 and SQ3000M2 combine AOI, SPI and coordinate measurement in a single machine, built on CyberOptics’ Multi-Reflection Suppression (MRS) sensors. MRS sensors reach 5 µm lateral and 0.1 µm height resolution, which is why the platform also serves mini LED, micro LED and advanced packaging inspection.
Features
Pros:
Cons:
8. ViTrox Technologies
Best for: dual-sided 3D AOI and AI programming at Asian EMS scale
ViTrox Technologies, headquartered in Penang, Malaysia, marked 25 years in 2025 and sells SPI, 3D AOI, AXI and robotic vision systems with offices in Germany and the United States. Its V510i DST dual-sided 3D AOI won the Circuits Assembly NPI Award in March 2025, and the V510Ai DST that followed in August 2025 offers 100 mm top clearance for THT assemblies. The V510i Semicon AOI and Micro AOI variants inspect wire bonds, die defects and solder bumps for advanced packaging.
Features
Pros:
Cons:
9. Parmi Co., Ltd.
Best AOI for High-Speed PCB Inspection in Asia
Operating out of South Korea, Parmi Co., Ltd. has made a significant mark in the AOI sector, gaining acclaim for its high-speed inline systems used in consumer electronics and automotive assembly across Asia. PARMI USA launched the company’s next-generation 3D AOI, the Xceed II, at IPC APEX EXPO in March 2025. As Juan Arango, Head of Sales and Business Development at PARMI USA, put it, the improvements in speed, precision and die inspection optimization make the Xceed II the company’s most advanced AOI system for high-demand, high-precision environments. In August 2025 PARMI USA appointed Prosperar Solutions as its representative in Brazil, extending Americas coverage.
Features
Pros:
Cons:
10. MEK Europe BV
Best desktop and compact AOI for European SMEs and THT lines
Mek (Marantz Electronics) developed its first AOI system in Japan in 1994, when Marantz was part of Philips, and shipped its first commercial desktop system in 1997. Mek Europe BV, based in Tilburg in the Netherlands, is the sales and support base for Europe, the Americas and India. With over 10,000 AOI machines in use worldwide as of 2024, Mek’s systems are widely adopted in quality control for PCB manufacturing and electronics assembly. They predominantly serve small to medium-sized enterprises across Europe, from the UK to Germany and down to Spain, which suits manufacturing engineers and production managers who prioritize quality without compromising on space or budget. Mek is a partner in the ITEA ExplAIn project with Prodrive, Signify and TU Delft, developing explainable AI for AOI in electronics manufacturing.
Features
Pros:
Cons:
Semiconductor and advanced packaging AOI manufacturers
Back-end fabs and OSATs buy AOI for die, wire-bond, bump and wafer-level defects at 1 to 5 µm, a different machine class from SMT AOI. Two specialists lead this segment on our list, and four SMT vendors above (Nordson, ViTrox, Mirtec and Koh Young’s Meister line) sell packaging variants. Front-end wafer inspection is a separate market: KLA and Onto Innovation dominate optical and e-beam wafer inspection in the fab, and those tools are covered under semiconductor visual inspection rather than here.
11. Camtek
Best for: advanced packaging and HBM inspection and 3D metrology
Camtek, headquartered in Migdal HaEmek, Israel, reported record 2025 revenue of USD 496.1 million, up from USD 429 million in 2024, driven by high-performance computing and advanced packaging. Its Eagle G5 and Hawk systems inspect and measure wafers from the mid-end through post-dicing, and Camtek is the tool of reference for HBM4 3D metrology at every major HBM manufacturer. In the third quarter of 2025, HPC applications were about 45 percent of revenue and other advanced packaging about 25 percent. For how Camtek’s approach compares with AI-based AOI, see Camtek inspection vs AI AOI.
Features
Pros:
Cons:
12. Machine Vision Products, Inc. (MVP)
Best AOI for aerospace, defense, medical and microelectronics packaging
Based in Vista, California, Machine Vision Products, Inc. (MVP) builds AOI for industries where precision is paramount: aerospace, defense and medical devices, plus die, wire-bond and BGA inspection for semiconductor packaging. In 2023, MVP proudly celebrated its 30th anniversary, reflecting its ability to adapt and thrive amidst the continuously evolving demands of manufacturing. In May 2025 MVP began assembling its flagship MVP 900 Series AOI systems in Malaysia to serve Asian electronics manufacturers, and at productronica in November 2025 it showed AI-driven defect detection for wafer, die, wire-bond, BGA and micro-assembly inspection.
Features
Pros:
Cons:
Comparison: Best Automated Optical Inspection Companies
How big is the AOI market in 2026?
The AOI equipment market is worth roughly USD 0.9 to 1.9 billion in 2025, depending on how analysts scope it. Grand View Research estimates USD 955 million in 2025 growing at 8.9 percent a year to 2033; 360iResearch estimates USD 1.61 billion in 2024 growing at 19 percent a year to USD 4.6 billion by 2030. The spread comes from whether software, SPI and semiconductor packaging inspection are counted.
For what individual machines cost by type and vendor, see AOI machine prices.
How To Choose The Best Automated Optical Inspection Company?
Six criteria separate the 12 manufacturers above. Score each vendor against your line before the demo, not after.
1. Inspection Speed vs. Precision
Higher speeds suit mass production; precision is the priority in regulated sectors such as aerospace and medical devices. Rated speeds and resolutions are published, so compare them directly.
2. 3D measurement, not just 3D imaging
3D measurement matters when solder volume, coplanarity and lifted leads are escaping 2D inspection. Moiré-based measurement (Koh Young, Mirtec, Saki, Omron) gives height data on every joint; laser-sensor 3D (TRI options, MVP Versa Duo) adds height on selected features at lower cost. Ask the vendor whether the 3D data is measured in microns or inferred from images.
3. Line integration: SPI, AXI and standards
Check how well the system integrates with the inspection steps around it and with your MES.
4. False-call rate and programming time
False calls are the operating cost of AOI: every call an operator reviews is labor, and every loosened threshold is an escape risk. In 2025 every vendor on this list ships AI-assisted programming or AI re-evaluation (Omron AI programming, Saki AI Assist, Viscom vAI Provision, ViTrox AI parameter checker, TRI Smart Programming). Ask for the false-call rate on your own boards during the demo, and for the time to program a new product from CAD.
5. Regional Availability and Support
The reach and support services of the provider can greatly impact operational efficiency and downtime.
6. Total cost and the software decision
Inline 3D AOI machines typically run from the tens of thousands into the low hundreds of thousands of dollars depending on resolution, 3D method and lane count; see AOI machine prices for a breakdown by type and vendor. Before replacing hardware to get better AI classification, check whether an AI software layer on your existing AOI machines closes the gap, which is the subject of the next section.
AI software that runs on top of AOI machines
AOI hardware and AI classification software are now separate buying decisions. Every machine above produces images and a first-pass defect call; an AI inspection layer can read those images, reclassify the calls, and cut the false-positive queue without changing the hardware.
Want 99%+ Accuracy From the AOI Machines You Already Own?
Add an AI inspection layer to your existing AOI fleet, no new hardware needed
Frequently Asked Questions
What is the primary benefit of using Automated Optical Inspection systems?
Automated Optical Inspection systems significantly enhance manufacturing quality control by providing high precision in defect detection, reducing human error, and increasing throughput speeds.
How does the SPI integration in AOI systems benefit manufacturing?
SPI integration in AOI systems streamlines the inspection process by combining solder paste inspection with optical checks, ensuring higher detection accuracy and smoother production lines. When both run on the same measurement principle, as at Koh Young, Saki, TRI and Nordson, paste volume data can be correlated with post-reflow joint defects and fed back to the printer.
What factors should you consider when upgrading to a new AOI system?
When upgrading, consider the new system’s compatibility with existing processes, its ability to scale with your production needs, and the level of technical support available from the provider. Also weigh total cost, covered in AOI machine prices, against an AI software upgrade on the machines you already own.
How does AI change automated optical inspection?
AI changes AOI in two places. In programming, AI generates inspection recipes from CAD and component libraries in minutes rather than hours, as Omron, Viscom and Saki now ship. In classification, AI models trained on a plant’s own defect images re-evaluate every call and reduce false positives, either inside the machine or as a separate software layer such as Averroes.ai running on existing AOI output.
What is the difference between an AOI machine and a machine vision system?
An AOI machine is a complete inspection station built for one job, usually PCB assembly or die and package inspection, with fixed optics, lighting, conveyor handling and defect libraries. A machine vision system from vendors such as Cognex or Keyence is a camera, lens and software toolkit that an integrator configures for any task, from code reading to presence checks. For that comparison, see Cognex vs Keyence vision systems.
Conclusion
Selecting the right AOI system is critical for manufacturing quality control.
Koh Young leads 3D AOI on installed base and measurement depth; Omron, Saki, TRI and Viscom are the established alternatives for SMT lines; Mirtec, Nordson, ViTrox and Parmi compete on resolution, speed or price; Mek serves European SMEs and THT; Camtek and MVP own the semiconductor and packaging segment.
When making your decision, consider the balance between inspection speed and precision, true 3D measurement, integration with SPI and AXI, false-call rate, regional support, and total cost. These factors will guide you toward the machine that fits your line.
Ready to improve classification accuracy on the AOI hardware you already run? Request a free demo from Averroes.ai and see how an AI inspection layer reaches 99 percent plus accuracy while working with your existing equipment.
